Product introduction:
Charging current: 50A
Banlance current: 100MA
Wiring method: same port
Size: length 14CM width 7CM thickness 1.7CM
Single cell voltage: detection range 1V-4.6V, accuracy less than 5Mv
Overcharged and paid: protected
Short circuit protection: short circuit protection current can be set
Bluetooth connection: for Android android hand sail
Applicable battery:
7S to -16S version ：
7-16S Li-ion Battery; 8-16SLifepo4 Battery;8-16S Titanium LTO lithium
8S to 20S version : 8S to 20S Li-ion Battery; 8S to 20S Lifepo4 Battery; 8S to 20S LTO Battery
Less than 96V pack version：suit for li-ion (3.65V/3.7V cells) 20S to 23S range ; Lifepo4 (3.2V cells) 20S to 26S range.
More than 96V pack version :suit for li-ion (3.65V/3.7V cells) 24S to 30S range ; Lifepo4 (3.2V cells) 26S to 30S range .
Coulomb counter: accurate calculation based on current versus time
Battery remaining capacity, error range is less than 5%
Power consumption: 3MA at work
1.5MA during standby
