Hybrid Inverter 24V 1000W Off Grid Low Frequency MPPT 60A Max Solar 120 Vdc Untuk PLTS Backup

CUBEPOWER 24V 1000W Inverter Hybrid Offgrid Low Frequency Inverter MPPT 40A

Garansi toko 12 bulan, garansi pabrik 2 tahun

Input LF 1KW 24 V :

1.Can be connected to generator or PLN

2.AC input voltage:145V-275V(220V),155V-285V(230V),165V-295V(240V)

3.Frequency:50Hz(45Hz-55Hz)/60Hz(55Hz-65Hz)

4.AC charging current:0-10A

5.Max. PV input voltage:120V

6.Max. PV input power: 1120W

Output LF 1KW 24 V :

1.Output voltage(Battery/PV mode):220V±2%/230V±2%/240V±2%

2.Output frequency(Battery/PV mode): 50Hz(45-55Hz)/60HZ(55-65Hz)

3.Output wave: pure sine wave

4.Transfer time:≤4MS 5.Output Efficiency(Battery/PV mode):>85%

6.Output Efficiency(AC mode):>99% 7.Output Voltage(AC Model):follow PLN(including Voltage and frequency)

Working mode: Battery Priority(PV Priority)/AC Priority

Protection: Battery under-voltage alarm, battery under-voltage protection, battery over-voltage alarm, battery over-voltage protection, battery over-voltage recovery, overload power protection, inverter output short circuit protection and temperature protection.
